In modern automation, robotics, and UAV systems, sensored motors are widely used for their stability, responsiveness, and precise control capabilities. To achieve smooth and accurate speed regulation across varying operating conditions, the motor driver plays a crucial role. The driver serves not only as the bridge between the control system and the motor but also as the core component for speed adjustment, torque control, and efficiency optimization. This article explains how to achieve speed regulation of a sensored motor through the driver, highlighting the main control methods and key optimization techniques.
Working Principle of Sensored Motors and Drivers
A sensored motor includes built-in detection devices—such as Hall sensors or encoders—to monitor rotor position and speed in real time. Based on these signals, the driver accurately controls current timing and phase to ensure smooth motor operation.
In the entire control system, the driver performs two main functions: current regulation and speed feedback control. By using PWM (Pulse Width Modulation) technology, it controls the magnitude of the output voltage and current to produce the desired torque and speed. Meanwhile, sensor feedback is used to dynamically adjust control parameters, ensuring stable operation even under changing load conditions.
Common Methods for Speed Control via Driver
1.Voltage Control Method
This method adjusts the output voltage of the driver to control motor speed. Higher supply voltage increases motor speed, while lower voltage reduces it. Although simple and fast in response, it offers limited precision and is more suitable for low-power or light-load applications.
2.PWM (Pulse Width Modulation) Control
PWM is the most widely used method for motor speed regulation. By varying the duty cycle (the ratio of “on” time to total period) of the PWM signal, the driver effectively changes the average output voltage. For instance, increasing the duty cycle from 50% to 80% raises the effective voltage, thus increasing motor speed. PWM control provides high efficiency, low heat generation, and smooth response—making it ideal for industrial applications.
3.Closed-Loop Feedback Control
For high-precision systems, the driver integrates with Hall sensors or encoders to form a closed-loop control system. The actual speed is continuously compared to the target speed, and the driver adjusts its output using a PID (Proportional–Integral–Derivative) algorithm. This allows highly accurate speed control with an error margin of less than 1%, making it the standard approach in automation and servo systems.
Key Technical Considerations in Speed Regulation
PID Tuning: Proper tuning of PID parameters prevents overshoot, oscillation, or lag, improving response and stability.
Dual-Loop Control (Current + Speed): Advanced drivers employ dual-loop structures—an inner current loop and an outer speed loop—to achieve superior dynamic performance.
Soft Start and Braking: Soft-start functions gradually ramp up voltage to prevent startup shocks, while braking mechanisms (dynamic or regenerative) ensure smooth deceleration.
Protection Features: High-quality drivers include built-in temperature, overcurrent, and voltage monitoring to protect both motor and controller from overload or damage.
Application Examples and Optimization Tips
In robotic and automated production lines, drivers often communicate with the main control system via CAN or RS485 interfaces for real-time remote speed control.
For example, in a conveyor system, the driver adjusts motor speed dynamically based on load weight, maintaining consistent production rhythm and minimizing energy waste.
For applications demanding extreme precision, implementing FOC (Field-Oriented Control) algorithms allows real-time decomposition of current vectors, providing smoother speed transitions and higher energy efficiency.
Conclusion
Speed control of sensored motors through drivers is a cornerstone of modern motion control systems. Well-designed drive circuits and optimized control algorithms not only enhance dynamic performance but also significantly reduce energy consumption and noise. With the integration of AI and IoT technologies, future motor drivers will become increasingly intelligent and adaptive, offering higher performance, greater efficiency, and more reliable power solutions for industrial automation and smart manufacturing.
