Description
| Parameter | Value |
|---|---|
| Model | BL3270AE |
| Motor Type | Coreless BLDC (High-Temp) |
| Diameter | Φ32mm |
| Length | 70mm |
| Nominal Voltage | 24V |
| No-Load Speed | 7,000 RPM |
| No-Load Current | ≤0.40A |
| Rated Torque | 105 mN·m |
| Rated Speed | 5,800 RPM |
| Rated Current | ≤4.5A |
| Peak Torque | 315 mN·m |
| Phase Resistance | 0.65Ω |
| Phase Inductance | 0.12 |
| Rotor Inertia | 25 g·cm² |
| Weight | ~155g |
| Operating Temp | -40~+180°C |
| Hall Sensor | Optional (120°/60°) |
| Applications | Downhole Motors, Steam Valves |
