Description
XTO-2306: The Ultimate 5-Inch FPV Freestyle Brushless Motor
The XTO-2306 is our best-selling 5-inch FPV motor with 710W max power, 1,372g of thrust on 5-inch tri-blades, and a lightweight 33g build. It delivers the perfect balance of punch, response, and efficiency for freestyle, racing, and cinematic flying.
Why Pilots Choose the XTO-2306
- 710W Peak Power — 1,372g thrust at full throttle on 4S with 5045 tri-blade props
- Two KV Options — 2450KV (4S freestyle sweet spot) and 2750KV (racing / 4S speed builds)
- 33g Weight — One of the lightest 2306 motors on the market
- Hollow Cooling Design — Manages heat during aggressive punch-outs
- 12N14P Stator — Smooth, predictable throttle curve
- Custom KV Winding — Need a 1750KV for 6S? We’ll wind it for you
Thrust Test Data (2450KV, 5045 Tri-Blade, 4S)
| Throttle | Current | Power | Thrust | Efficiency |
|---|---|---|---|---|
| 30% | 1.40A | 15.5W | 50g | 3.22 g/W |
| 50% | 3.14A | 34.9W | 100g | 2.87 g/W |
| 85% | 12.15A | 134.9W | 284g | 2.11 g/W |
| 100% | 43.54A | 644.4W | 1,372g | 2.13 g/W |
Recommended Pairing
| Component | 4S Build | 6S Build |
|---|---|---|
| Motor KV | 2450KV or 2750KV | 1750KV (custom) |
| ESC | 55A 4-in-1 | 45A 4-in-1 |
| Propeller | 5045 tri-blade | 5030-5040 tri-blade |
| Battery | 4S 1500mAh 100C | 6S 1300mAh 100C |
FAQ
Q: 2450KV or 2750KV?
A: 2450KV for all-around freestyle. 2750KV for maximum speed.
Q: Can I run 6S on 2450KV?
A: No — 2450KV x 22.2V pulls excessive current. Use custom 1750KV for 6S.
